Forensic Radiology Specimes (Labeled)

Photo:
no fusion of epi & diaphysis in any bone, 15-16 yrs
Photo:
Non fusion tibia <16 female <18 male
R738 has partial fusion 16-18 female and 18-20 male
Photo:
hyoid less than 40
Photo:
>70 years
Photo:
Non fusion < 30 years age
Photo:
Only calcaneum visible so non viable (left)
Photo:
Talus present but lower end absent hence viable but not full term
Photo:
FTF written which means full term fetus meaning talus present + lower end of femur present as well
Photo:
Greater trochanter and head full fusion? if so age 20-21
Photo:
Pisiform is present >12 but <17 years age because no fusion of wrist
Photo:
Hyoid bone clearly not fused so age <40
Photo:
not full term, not viable, no talus centre


Photo:
incomplete fusion at lower ends of tibia & fibula, 21-22 yrs.
Photo:
all carpels visible, no fusion at wrist joint, 15-16 years
Photo:
no triradiate cartilage & no gap in iliac crest, no cartilage disc at medium end of clavicle, coronal suture fused, sagittal anterior one 3rd fused, age 25-30 yrs
Photo:
incomplete fusion at wrist, 21-22 years
Photo:
head & greater trochanter of femur starting to fuse, 19-20 years
Photo:
no fusion at both joints,,15-16 yrs

Photo:
Right side: non fusion <16f and < 18 male
Left side partial fusion? Then 14-16 f and 16-18 male

Photo:
no fusion at lower end of tibia, less than 17 years



Photo:
full term & viable,femur & talus centre present
Photo:
not full term but viable, talus centre present 2
Photo:
full term & viable, femur lower end & talus centre present 4
Photo:
not full term but viable,talus centre present 2
Photo:
not full term &  not viable,talus centre absent, calcaneum present

Photo:
no fusion , 15-16 years
